Core Advantages
1. Superior Surface Performance
·Scratch and Wear Resistance: The organic silicone coating has high hardness, and daily friction and fingernail scratches do not leave marks.
·Stain Resistance and Easy Cleaning: Oil stains, fingerprints, and ink are easily wiped away, and it does not yellow over long-term use.
·Smooth and Non-sticky: The surface has a delicate and smooth feel, and it does not attract dust or stick to hands.
2. Strong Weather Resistance and Stability
·High and Low Temperature Resistance: Adaptable to large temperature differences, it does not become sticky at high temperatures and does not crack at low temperatures.
·UV Resistance: It does not easily fade, deform, or chalk in outdoor/sunlight environments.
3. Dimensional Stability: Adhesive to thermal expansion and contraction, ensuring a smooth, bubble-free, and edge-free fit.
4. Environmentally Friendly and Safe: Low odor, environmentally friendly and non-toxic: Meets home environmental standards, with no pungent odor.
5. Mold and Antibacterial: Dense surface, resistant to mold growth, suitable for kitchens, bathrooms, and humid environments.
6. Flame Retardant Optional: Can be modified for flame retardancy to meet building material and appliance safety requirements.
7. Good Processing and Adaptability: Easy to vacuum-form and wrap: Good flexibility, adaptable to irregularly shaped door panels and curved surfaces.
8. Excellent Printing and Lamination: Can be applied with various effects such as wood grain, stone grain, solid colors, and skin-like finishes.
9. Strong Compatibility: Adheses well with wood glue and wrapping adhesives, ensuring smooth installation.
10. High-End Texture: Available in skin-like, matte, and silky finishes, far surpassing the quality of ordinary PVC film.
Smooth and uniform surface, free of orange peel texture, offering a high-end visual appeal and comfortable touch. In summary, silicone PVC film is scratch-resistant, stain-resistant, has a delicate feel, is weather-resistant, environmentally friendly, and easy to process, making it an ideal surface material for high-end furniture, door panels, and decorative finishes.
| Technical Specifications |
Regulations, Test Methods, and Evaluation Standards |
Reference Values |
| Restricted Substances |
EU REACH-SVHC and RoHS Environmental Regulations |
Complies |
| Restricted Substances |
Volatile Organic Compounds (VOCs), Formaldehyde |
No additives |
| Odor |
German Volkswagen Interior Standard VDA 270-2022, Class D, 40°C |
≤Grade 2.5 |
| Dimensional Stability |
GB/T 12027-2004 |
≤3% |
| Abrasion Resistance |
GB/T 17657-2022 §4.45—Method 1 (ISO 4586-2:2018 §11) |
≥500 cycles |
| Scratch Resistance |
GB/T 17657-2022 §4.42 (ISO 4586-2:2018 §29) |
≥1.0 N |
| Chemical Resistance |
Strong acid, 10% hydrochloric acid, ISO 4582-2:2004 |
Grade 5 gray card |
| Strong alkali, 25% sodium hydroxide, ISO 4582-2:2004 |
Grade 5 gray card |
| Strong oxidizing agents, 30% hydrogen peroxide, ISO 4582-2:2004 |
Grade 5 gray card |
| 75% ethanol, ISO 4582-2:2004 |
Grade 5 gray card |
| Stain Resistance |
Shoe polish, ISO 4582-2:2004 |
Grade 5 gray card |
| Black coffee, ISO 4582-2:2004 |
Grade 5 gray card |
| Povidone-iodine, ISO 4582-2:2004 |
Grade 5 gray card |
| Red ink, ISO 4582-2:2004 |
Gray Card Level 5 |
| Yellowing Resistance |
GB/T 23983-2009, UVA-340, 0.68 W, after 168 hours |
△E ≤ 1.0 |
| High-Temperature Resistance |
In-house method |
≥ 200°C |
| Flame Retardancy |
Directly flame-test using a butane torch |
No dripping, no ignition |
| *Gray card, Level 5: When evaluated according to ISO 105/A02 (i.e., GB 250), no visible changes are observed. |
